Wall-Mounted EcoMax G2

LEDWall-Mounted-E2 Rd275-22W-MD-EM3

Product Code
522020001100
  • Stylish, compact and sturdy wall mounted fixture (IP54+IK08)
  • Easy wiring with through-wiring possibility
  • Integrated CCT switch for color selection (3000K-4000K)

Specifications

Electrical data

Voltage type AC
Max. system power 22 W
Power factor 0.9
Frequency 50|60 Hz
Nominal voltage 220|240 V
Max. number of luminaires per miniature circuit breaker B16 (MCB) 84
Max. number of luminaires per miniature circuit breaker C16 (MCB) 84
Max. inrush current 28.00 A
Inrush time 25.7
Displacement factor (DF) ≥ 0.9
Max. number of luminaires per miniature circuit breaker C10 (MCB) 52
Max. number of luminaires per miniature circuit breaker C13 (MCB) 68

Photometrical data

Colour temperature 3000|4000 K
Rated luminous flux according to IEC 62722-2-1 2500 lm
Luminaire efficacy 115 lm/W
Colour consistency (SDCM) 4
Equivalent to CFL 2x26W
Colour rendering index (CRI) > 80
CIE Flux Code 44 74 93 97 100

Light technical data

Beam angle 120°

Lifespan

Lifetime (L70) 50000 h
Lifetime (L80) 30000 h
On-/Off-cycles 100000

Capabilities

Dimmability Sensor controlled (MD)
With sensor Yes
Sensor technology Microwave (MW)
Sensor type Motion + Daylight detection (MD)

Certificates and standards

Degree of protection (IP) IP54
Protection class II
Risk group (EN 62471) RG0
Impact strength IK08
Glow wire test 850°C
Type of control gear LED operating device current-controlled
With control gear Yes
Driver failure rate (at 5,000 hrs) 0.5%
Input current 0.1400 A
Wirethrough No
Housing colour White
Optical material Polycarbonate
Cover material Polycarbonate
Finishing White RAL9016
Length 275 mm
Width 275 mm
Height/depth 71 mm
Outer diameter 275 mm
Application temperature 25°C
Storage environment -30|60°C
Storage environment EM -20|25°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
0694140888420294054239CT10.285 x 0.285 x 0.08 m1.142 KG
