Floodlight EcoMax G3

LEDFlood-E3 Re300-150W-840-BL-AS

Product Code
709000116500
  • Complete floodlight family from 10 to 200W
  • Equipped with breather to prevent condensation

Specifications

Electrical data

Nominal voltage 220|240 V
Voltage type AC
Max. system power 150 W
Max. number of luminaires per miniature circuit breaker B16 (MCB) 6
Max. number of luminaires per miniature circuit breaker C16 (MCB) 10
Power factor 0.9
Surge protection 4 kV
Max. inrush current 52.4 A
Inrush time 400
Displacement factor (DF) ≥ 0.9
Max. number of luminaires per miniature circuit breaker C10 (MCB) 6
Max. number of luminaires per miniature circuit breaker C13 (MCB) 8
Frequency 50|60 Hz

Photometrical data

Colour temperature 4000 K
Rated luminous flux according to IEC 62722-2-1 22500 lm
Luminaire efficacy 150 lm/W
Equivalent to HID 400W
Colour consistency (SDCM) 4
Colour rendering index (CRI) > 80
CIE Flux Code 53 91 99 100 100

Light technical data

Beam angle 75° x 100°

Lifespan

Lifetime (L70) 50000 h
Lifetime (L80) 30000 h
On-/Off-cycles 100000

Capabilities

Dimmability On-Off
With sensor F
Sensor technology No sensor
Sensor type No sensor

Certificates and standards

Protection class I
Degree of protection (IP) IP66
Impact strength IK07
Glow wire test 850°C
Risk group (EN 62471) RG1
Type of control gear LED operating device current-controlled
With control gear Yes
Driver failure rate (at 5,000 hrs) 0.5%
230V Cable length 1 m
Housing colour Black
Optical material Polycarbonate
Cover material Tempered glass
Pressure valve Yes
Coastal proof Yes
Length 350 mm
Width 288 mm
Height/depth 45 mm
Application temperature 25°C
Storage environment -40|60°C
Operating temperature -30|50°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
694149173714094054239CT10.363 x 0.372 x 0.049 m3.54 KG

Accessoires



Accessory Outdoor - Connector kit - 3 Wires - IP68

Product Code
543098021900
Coupler/connector straight


Accessory Outdoor - Extension cable - 6m

Product Code
705000141900
Connecting cable
