| Nominal voltage | 220|240 V |
|---|---|
| Voltage type | AC/DC |
| Max. system power | 72 W |
| Max. number of luminaires per miniature circuit breaker B16 (MCB) | 12 |
| Max. number of luminaires per miniature circuit breaker C16 (MCB) | 24 |
| Power factor | 0.95 |
| Surge protection | 2 kV |
| With sensor | No |
| Max. inrush current | 52.5 A |
| Inrush time | 173.6 |
| Displacement factor (DF) | ≥ 0.95 |
| Max. number of luminaires per miniature circuit breaker C10 (MCB) | 15 |
| Max. number of luminaires per miniature circuit breaker C13 (MCB) | 19 |
| Including emergency lighting | 3 Hours |
| Nominal voltage DC | 180|260 V |
| Frequency | 50|60 Hz |
| Colour temperature | 4000 K |
|---|---|
| Lumen | 12240 lm |
| Luminaire efficacy | 170 lm/W |
| Equivalent to | TL 2x80W |
| Colour consistency (SDCM) | 4 |
| Colour rendering index (CRI) | > 80 |
| CIE Flux Code | 41 70 89 88 100 |
| Beam angle | 120° |
|---|---|
| Beam angle | 120° |
| Lifetime (L70) | 100000 h |
|---|---|
| Lifetime (L80) | 100000 h |
| On-/Off-cycles | 100000 |
| Dimmability | DALI2 |
|---|---|
| With sensor | No |
| Protection class according to IEC 61140 | II |
|---|---|
| Degree of protection (IP) | IP66 |
| Impact strength | IK08 |
| Glow wire test | 850°C |
| Risk group (EN 62471) | RG0 |
| Type of control gear | LED operating device current-controlled |
|---|---|
| With control gear | Yes |
| Driver failure rate (at 5,000 hrs) | 1% |
| Input current | 0.344 A |
| Max. input cable diameter | 7|15.5 mm |
| Wirethrough | No |
| Internal wiring (mm2) | 5x2.5 |
| Housing colour | Grey |
|---|---|
| Cover material | PC |
| Finishing | Grey RAL 7035 |
| Pressure valve | No |
| Coastal proof | No |
| Length | 1580 mm |
|---|---|
| Width | 73 mm |
| Height/depth | 71 mm |
| Application temperature | 25°C |
|---|
| EAN code | EU HS Code | Packaging | Amount | Size (L x W x H) | Weight |
|---|---|---|---|---|---|
| 6941491795317 | 94051190 | CT | 1 | 1.587 x 0.079 x 0.076 m | 2.24 KG |
