LEDWaterproof-E4 L15-23/43W-857

Electrical data

Nominal voltage	220|240 V
Voltage type	AC/DC
Power factor	0.95
Max. system power	43 W
Max. number of luminaires per miniature circuit breaker B16 (MCB)	28
Max. number of luminaires per miniature circuit breaker C16 (MCB)	49
Surge protection	2 kV
With sensor	No
Max. inrush current	17.7 A
Inrush time	224
Max. number of luminaires per miniature circuit breaker C10 (MCB)	30
Max. number of luminaires per miniature circuit breaker C13 (MCB)	39
Including emergency lighting	No
Frequency	50|60 Hz
Nominal voltage DC	180|260 V

Photometrical data

Colour temperature	5700 K
Equivalent to	TL 1/2x58W
Colour consistency (SDCM)	4
Colour rendering index (CRI)	> 80

Light technical data

Beam angle	120°
Beam angle	120°

Lifespan

Lifetime (L70)	100000 h
Lifetime (L80)	100000 h
On-/Off-cycles	100000
Lifetime (L90)	50000 h

Capabilities

Dimmability	On-Off
With sensor	No

Certificates and standards

Protection class according to IEC 61140	II
Impact strength	IK08
Glow wire test	850°C
Risk group (EN 62471)	RG0

Type of control gear	LED operating device current-controlled
With control gear	Yes
Driver failure rate (at 5,000 hrs)	1%
Input current	0.206 A
Wirethrough	No

Finishing	Grey RAL 7035
Housing colour	Grey
Cover material	Polycarbonate
Pressure valve	No
Coastal proof	No

Length	1580 mm
Width	63 mm
Height/depth	62 mm

Storage environment	-30|60°C
Application temperature	25°C
Operating temperature	-30|45°C
