Desk Lamp Balance

LEDBalance-P 14W-DIM-830/840/850

Product Code
523003012900
  • Stylish design desk lamp with 320-degree rotation
  • Advanced optics with wider illumination area and higher uniformity
  • Forward light design, no shadow in front of the hands
  • Touch-button control for dimming and scene/CCT change
  • Daylight control sensor, automatically optimizes the light

Specifications

Electrical data

Voltage type AC
Power factor 0.7
Frequency 50|60 Hz
Nominal voltage 220|240 V
Surge protection 0.5 kV

Photometrical data

Colour consistency (SDCM) 4
CIE Flux Code 40 78 96 100 100

Lifespan

Lifetime (L70) 50000 h
Lifetime (L80) 30000 h
On-/Off-cycles 100000

Certificates and standards

Protection class II
Glow wire test 650°C
Type of control gear LED operating device current-controlled
With control gear Yes
Driver failure rate (at 5,000 hrs) 1%
Input current 0.076 A
230V Cable length 1.8 m
Housing colour Grey
Mounting method Stand (base)
Optical material Polycarbonate
Cover material Polycarbonate
Lens material Polycarbonate
Height 570 mm
Height/depth 570 mm
Storage environment -25|50°C
Application temperature 25°C
Operating temperature -10|40°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
694149173701094051190CT10.282 x 0.23 x 0.57 m1.65 KG
