Lima

LEDLima L15-36W-4000-BLE2

Product Code
542003132200
  • Stylish linear luminaire with high quality aluminum housing, suitable for surface mounting and suspended use
  • Suspension kit including transparent cable as accessory
  • Connection kit accessory to create continuous lines available
  • Available in DALI and Smart (BLE2)

Specifications

Electrical data

Voltage type AC
Power factor 0.9
Max. number of luminaires per miniature circuit breaker B16 (MCB) 15
Max. number of luminaires per miniature circuit breaker C16 (MCB) 26
Frequency 50|60 Hz
Nominal voltage 220|240 V
Max. inrush current 20.00 A
Inrush time 400.0
Displacement factor (DF) ≥ 0.9
Max. number of luminaires per miniature circuit breaker C10 (MCB) 16
Max. number of luminaires per miniature circuit breaker C13 (MCB) 21
Nominal voltage DC 180|280 V

Photometrical data

Colour consistency (SDCM) 3
CIE Flux Code 68 91 98 100 100

Lifespan

Lifetime (L70) 70000 h
Lifetime (L80) 50000 h
On-/Off-cycles 100000

Certificates and standards

Degree of protection (IP) IP20
Protection class I
Risk group (EN 62471) RG0
Impact strength IK02
Glow wire test 650°C
Type of control gear LED operating device current-controlled
With control gear Yes
Driver failure rate (at 5,000 hrs) 0.5%
Housing colour Aluminium
Optical material Polycarbonate
Height/depth 75 mm
Storage environment -25|50°C
Application temperature 25°C
Operating temperature -10|45°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
0694149778007294051190CT11.574 x 0.075 x 0.075 m3.66 KG

Accessoires



Accessory Smart Lighting - Sensor surface module - White

Product Code
560098000600
Surface mounted housing


Accessory Lima - Connection kit

Product Code
599006008900
Coupler/connector straight


Accessory Lima - Suspension kit

Product Code
599006009000
Suspension cable


Accessory Smart Lighting - Sensor recessed - Microwave (MW)

Product Code
821006001800


Accessory Smart Lighting - Sensor recessed - Passive Infrared (PIR)

Product Code
821006002000


Accessory Smart Lighting - Switch

Product Code
821009000200


Accessory Smart Lighting - Connect box

Product Code
821011002600


Accessory Smart Lighting - Multi switch module

Product Code
821017003400


Accessory Smart Lighting - Relay - 1000 Watt

Product Code
821017003800

Downloads
