| Nominal voltage | 220|240 V |
|---|---|
| Voltage type | AC/DC |
| Max. system power | 20 W |
| Max. number of luminaires per miniature circuit breaker B16 (MCB) | 53 |
| Max. number of luminaires per miniature circuit breaker C16 (MCB) | 84 |
| Power factor | 0.9 |
| Max. inrush current | 25 A |
| Inrush time | 80 |
| Displacement factor (DF) | ≥ 0.9 |
| Max. number of luminaires per miniature circuit breaker C10 (MCB) | 52 |
| Max. number of luminaires per miniature circuit breaker C13 (MCB) | 68 |
| Nominal voltage DC | 180|280 V |
| Frequency | 50|60 Hz |
| Colour temperature | 4000 K |
|---|---|
| Equivalent to | HID 35W |
| Colour consistency (SDCM) | 4 |
| Colour rendering index (CRI) | > 90 |
| R9 | 50 |
| TM-30-Rf | 97 |
| TM-30-Rg | 91 |
| Beam angle | 36° |
|---|
| Lifetime (L70) | 70000 h |
|---|---|
| Lifetime (L80) | 50000 h |
| On-/Off-cycles | 100000 |
| Dimmability | On-Off |
|---|
| Protection class according to IEC 61140 | II |
|---|---|
| Impact strength | IK03 |
| Glow wire test | 650°C |
| Risk group (EN 62471) | RG1 |
| Type of control gear | LED operating device current-controlled |
|---|---|
| With control gear | Yes |
| Driver failure rate (at 5,000 hrs) | 1% |
| Finishing | Matte White |
|---|---|
| Housing colour | White |
| Reflector | High-gloss |
| Optical material | Polycarbonate |
| Cover material | Polycarbonate |
| Lens material | Polycarbonate |
| Maximum tilt angle | 85° |
| Length | 162 mm |
|---|---|
| Width | 155 mm |
| Height/depth | 70 mm |
| Outer diameter | 70 mm |
| Storage environment | -25|50°C |
|---|---|
| Application temperature | 25°C |
| Operating temperature | -10|35°C |
| EAN code | EU HS Code | Packaging | Amount | Size (L x W x H) | Weight |
|---|---|---|---|---|---|
| 6937209609410 | 94051190 | CT | 1 | 0.153 x 0.074 x 0.212 m | 0.5575 KG |
