Spot Ava G2

LEDSpotRA-Ava-E2 7W-Dim-2700-30D-BA

Product Code
541003207700
  • Modern reccessed LED Spot with 25° tilting angle for perfect scene setting
  • Standard fully IP44, ideal for damp applications like bathrooms
  • Beam angle of 30° provides an accent lighting effect
  • Comforting warm white light tone (2700K) perfect for creating cozy ambience

Specifications

Electrical data

Max. system power 7 W
Voltage type AC
Nominal voltage 220|240 V
Frequency 50/60 Hz
Nominal voltage DC 180|230 V
Power factor 0.9
Max. inrush current 2.62 A
Inrush time 175 µs
Max. number of luminaires per miniature circuit breaker B16 (MCB) 314
Max. number of luminaires per miniature circuit breaker C16 (MCB) 314
Max. number of luminaires per miniature circuit breaker C13 (MCB) 255
Max. number of luminaires per miniature circuit breaker C10 (MCB) 196

Photometrical data

Colour rendering index (CRI) > 80
Equivalent to Halogen 50W
Rated luminous flux according to IEC 62722-2-1 520 lm
Luminaire efficacy 74 lm/W
Colour consistency (SDCM) 4
CIE Flux Code 93 98 100 100 100

Light technical data

Beam angle 30°

Lifespan

Lifetime (L70) 50000 h
Lifetime (L80) 30000 h
On-/Off-cycles 100000

Capabilities

Dimmability Triac

Certificates and standards

Degree of protection (IP) IP44
Impact strength IK02
Protection class II
Glow wire test 750°C
Risk group (EN 62471) RG0
With control gear Yes
Type of control gear LED operating device current-controlled
Driver failure rate (at 5,000 hrs) <0.5%
Input current 0.04 A
230V Cable length 0.3 m
Housing colour Aluminium
Optical material Polycarbonate
Reflector High-gloss
Finishing Brushed Aluminum
Maximum tilt angle 25°
Length 85 mm
Width 85 mm
Height/depth 53 mm
Outer diameter 85 mm
Weight 0.22 kg
Application temperature 25°C
Operating temperature -10|45°C
Storage environment -25|50°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
0694140887012094051190Carton1140 x 125 x 70 mm0.313 kg

Accessoires



Accessory Indoor - Junction box - White

Product Code
542098030700
Coupler/connector straight


Accessory Smart Lighting - Relay - 250 Watt - Dimmable

Product Code
821017003600
Signal converter
